Flat-Type Gas Infrared Burner
- Infrared radiation heating is taken as dominant method, supplemented by convection heating (65% radiation, 35% convection), which saves 30-50% energy compared with electric drying.
- The structural design made of high-temperature resistant alloy fiber sintering is adopted, which is durable.
- The mechanical fire protection device is designed, and the electronic monitoring tempering detection needle is also designed to link with the control part of the whole system, so that the whole system achieves a safe, reliable, efficient and energy-saving burner system.
- It can be combined into heating equipment of different specifications according to needs, and the combustion surface can be installed in any aspect of upper, lower and side surfaces, which is convenient to replace.
- Low CO: Combustion is more sufficient because it is completely premixed combustion.
- The integrated structural design makes the working environment more comfortable and quiet.
- Natural premixing: The preset gas/air premixing device enables the burner to obtain a good gas/air ratio. Moreover, the whole process is completed automatically without manual intervention.
Industry Application：
1、Food drying
2、Drying of painting line
3、TPXRP drying，Coating drying
4、Paper drying and heating
5、Cereal baking and heating
6、Washing drying and heating
7、Latex products drying
8、Gas water heater
9、Asphalt pavement repair
Dimension：
1、Heating range of unit area is 150~350kw/㎡
2、Surface temperature up to 800℃
3、High adjustment ratio, up to 1:6
4、Dimensions according to customer requirements non-standardized custom design
